Duratron U1000 PEI
Duratron U1000 PEI is an unfilled polyetherimide grade offering high tensile strength and heat resistance up to 170°C, combined with dimensional stability and consistent machinability.
Specifications
- Minimum Operating Temperature
- -50°C
- Maximum Operating Temperature
- 170°C
- Food Grade
- Yes
- Drinking Water Approved
- No
- Tensile Strength (MPa)
- 129
- Thermal Expansion (µm/m.K)
- 50
- Coefficient of Friction
- N/A
- Chemical Resistance
- Medium
- Formats Available
- Rod, Sheet
Duratron U1000 PEI is a high-performance polyetherimide (PEI) grade recognised for its excellent mechanical strength and heat resistance. With a tensile strength of 129 MPa and a continuous service temperature of 170°C, it maintains structural integrity in demanding thermal environments while also performing reliably at temperatures as low as -50°C.
This material exhibits a low coefficient of thermal expansion (50 x 10⁻⁶/°C), contributing to dimensional stability in precision components. Its medium chemical resistance makes it suitable for exposure to a range of industrial fluids. Dotmar supplies Duratron U1000 PEI as machinable rod and sheet stock, backed by technical expertise in engineering plastics for Australian industry.
Key Features
- High tensile strength of 129 MPa
- Continuous service temperature up to 170°C
- Low-temperature performance down to -50°C
- Low thermal expansion coefficient of 50 x 10⁻⁶/°C
- Medium chemical resistance
- Available in rod and sheet formats
Duratron U1000 PEI is commonly specified for medical device components, electrical insulators, semiconductor wafer handling equipment, and aerospace interior parts. Its combination of strength, thermal stability, and dimensional accuracy also suits it for high-precision industrial tooling and fluid handling components where consistent performance under load and temperature cycling is required.
